• New
Ev Wall Home, 22 kW

Ev Wall Home, 22 kW

€1,079.67
VAT included
Ev Wall Home, 22 kW
Quantity

Smappee
0159597
  Beveiligingsbeleid

(bewerken met de module Klantenverzekering)

  Leveringsbeleid

(bewerken met de module Klantenverzekering)

  Retourbeleid

(bewerken met de module Klantenverzekering)

The load capacity is a maximum of 22 kW and can be controlled static or dynamically. The Infinity kit (0159658) is required for dynamic overload protection. The connection requires an Ethernet connection.
The Smappee EV Wall Home is a smart charging station for electric vehicles with one connection. The device impresses with its user-friendly installation, which is quick and easy thanks to the simple cable configuration and an installation wizard. The EV Wall Home is available with a loading socket and supports various payment options. The EV Wall Home package includes a 5-year subscription to the SMART subscription, which offers advanced functions. Additional extensions are also available as optional accessories.
Product advantages:
• Intelligent charging station
• User-friendly installation
• Supports various payment options
• EV Wall Home package and optional extras
• Connection in accordance with Enwg § 14a via external accessories
Product:
• Maximum load capacity per charging point: 22 kW
• Access control: RFID (cards must be ordered separately), QR code
• AC power grid voltage: 230/400 V
• Input phases: 3-phase
• Phase switching: Yes, with Infinity kit (0159658)
• Mid-meter: yes
• Calibrated: No
• Meets ISO 15118-2: no
• Compliant to ENWG § 14a: Yes (with Infinity Kit (0159658) / SG Ready Module (0161749))
• Interfaces: WiFi, Ethernet
• Protection class: IP54
• Dimensions: 110 x 300 x 300 mm
• Weight without packaging: 7.3 kg
